• Danfoss  134G6277 (FC-202N400T7E54H2XGCXXXSXXXXAXBXCXXXXDX) 500HP 395A IP54 VLT Aqua Drive FC-202

134G6277 Danfoss

Factory New

Available to order

  • $45,198.00

7-10 Days Delivery!

Manufacturer Warranty!

Secure Checkout!


AFi Inventory Options

Click below to highlight option.

7-10 Days Delivery!

2 Year AFI Warranty!

Secure Checkout!

Eco Friendly Option!

Danfoss 134G6277 (FC-202N400T7E54H2XGCXXXSXXXXAXBXCXXXXDX) 500HP 395A IP54 VLT Aqua Drive FC-202

The 134G6277 is an optimised drive for AC motor driven water and wastewater applications, with a continuous output of 500HP, or 395A and running off a Three Phase 525-690V supply.

User friendly programming makes installation simple and enables owners to reach the maximum level of performance and lowest cost of ownership. Set up the 134G6277 quickly and easily with the user friendly dialogue based Smart Start, and a quick menu. The quick menu provides direct access to the most important parameters for water and pump applications, by collecting these in one place, the risk of incorrect configuration is reduced significantly.

Featuring a large selection of powerful, standard features, which can be expanded with performance improving options, the VLT® AQUA Drive is equally suited to both new and retrofit projects.  Features such as dry run detection and flow confirmation help to protect your pumps and deragging can be performed as either preventative or reactive cleaning.  Motor alternation and cascade controller helps to save energy and reduce equipment costs.  These are only a few of the dedicated pumping features of the 134G6277

The 134G6277 is also referred to as FC-202N400T7E54H2XGCXXXSXXXXAXBXCXXXXDX.

As an approved Danfoss service centre, AFi are also able to offer repairs of the 134G6277, along with field service, installation and commissioning support and selection advice.  Our experienced team also provide upgrade advice and implementation and control panel design and build.

134G6277 Specifications

AC Drive Brake Chopper No
AC Drive Communications Modbus Comms
AC Drive Conformal Coating Yes
AC Drive Filter Class A2 (C3)
AC Drive Heavy Duty Output (kw) 355
AC Drive Input Voltage (VAC) 525-690V
AC Drive Keypad Yes
AC Drive Logic Positive, Negative
AC Drive Loop Open Loop
AC Drive Normal Duty Output (kw) 400
AC Drive Nr Analog Inputs 2
AC Drive Nr Analog Outputs 1
AC Drive Nr Digital Inputs 6
AC Drive Nr Digital Outputs 2
AC Drive Nr Relay Outputs 2
AC Drive Phase Three Phase
AC Drive Protection IP54
AC Drive Pulse Input 2
AC Drive Safe Torque Off No
AC Drive Heavy Duty Output (HP) 500
AC Drive Heavy Duty Output (Amps) 395
