Image shown is a representation only. Actual product may vary -
-
-
-
Siemens 6SL3544-0LB02-1FA0 Sinamics G110 Control Unit
The 6SL3544-0LB02-1FA0 is a Sinamics G110 CU240M control unit by Siemens /w/ 24VDC supply. Supports communications over PROFIBUS /w/ 4x DI, 2x DQ and 1x AI terminals.
IP66 rated enclosure, measuring 105mm x 171mm x 205mm and weighing 1.8kg.
6SL3544-0LB02-1FA0 Specifications
| Ingress Protection Rating | IP66 |
| Drive Loop | Open |
| Drive Communications | PROFIBUS |
| No. of Digital Inputs | 4 |
| No. of Analog Inputs | 2 |
| No. of Digital Outputs | 2 |
| PTC/KTY Input | 1 |
