Hydac EDS 346-2-600-000 Pressure Sensor
Hydac Pressure Sensor
Burst Pressure: 2000 bar
Connection Size: G1/4 A
Connection Type: ISO 1179-2
Degree of Protection: IP 65
Switch Type: 2 PNP Transistor Switching Outputs
Switching Current: 1.2 A
Switching Function: Adjustable N/O or N/C
Electrical Connection: Male M12x1, 4 Pole
Only Possible on Output Models "1", "2" and "3"
(Mating Connector Not Supplied)
Interface: 3-Digit, LED, 7 Segment, Red, Height of Digits 9.2 mm
Max Operating Temperature: -25 to 80 °C
Output Signal: 2 Switching Outputs Only in Conjunction with Electrical Connection Type "4" or "6"
Max Pressure: 1000 bar
Seal Material: Fluorocarbon Elastomer (FKM)
Industry Standards/Certifications: EN 61000-6-1/2/3/4
