MK 25 NC Muller

Muller Coax Group MK252C116TVB1P2AXB Coaxial Direct Acting Valve

Muller Coax Group Coaxial Direct Acting Valve

Ports: 1 - 1 1/2 NPT threads

ANSI 150/600/1500 flanges

Function: NC / NO

Pressure range: 0-232 / 0-580 / 0-913.5 / 0-1450 psi

CV value: 15.03 GPM

Media: gaseous  liquid  highly viscous  gelatinous  contaminated 

Flow direction: A→ B as marked

Switching cycles: 130 1/min

Switching time: opening 130 ms

closing 130 ms

Media temperature: DC -4 °F — +212 °F

AC -4 °F — +212 °F

Ambient temperature: DC -4 °F — +176 °F

AC -4 °F — +176 °F

Weight: MK 8.0 kg

FK 10.5 kg

Nominal voltage: Un 24 V DC +5% / -10%

Un 230 V 40-60 Hz AC +5% / -10%

Actuation: DC direct-current magnet

AC direct-current magnet with integrated rectifier

Insulation rating: H 180 °C

protection: IP65

Energized duty rating: ED 100%

Connection: plug acc. DIN EN 175301-803, form A, 4 positions x 90°, wire diameter 6-8 mm

M12x1 connector acc. DESINA / VDMA
