IFM Efector OJ5004 / OJP-FPKG FO AS RETRO-REFLECTIVE SENSOR
IFM Efector Retro-reflective sensor
Type of light: red light
Housing: rectangular
System: polarization filter
Function principle: Retro-reflective sensor
Operating voltage[V]: 10...30 DC
Current consumption[mA]: < 22
Protection class: III
Reverse polarity protection: yes
Type of light: red light
Wave length[nm]: 660
Electrical design: PNP
Output function: light-on/dark-on mode; (programmable)
Max. voltage drop switching output DC[V]: 2.5
Permanent current rating of switching output DC[mA]: 200
Switching frequency DC[Hz]: 2000
Short-circuit protection: yes
Type of short-circuit protection: yes (non-latching)
Overload protection: yes
Range referred to prismatic reflector[m]: 0...2; (Prismatic reflector Ø 80 E20005)
Range adjustable: yes
Max. light spot diameter[mm]: 64
Light spot dimensions refer to: at maximum range
Polarization filter available: yes
Ambient temperature[°C]: -25...60
Protection: IP 67
EMC: EN 60947-5-2
MTTF[years]: 867
Weight[g]: 32.15
Housing: rectangular
Dimensions[mm]: 35 x 24 x 11
Material: housing: ABS; fixture: diecast zinc; LED window: SEPS; pushbutton: SEPS
Lens material: glass
Lens alignment: Front sensing
Display: Switching status1 x LED, yellowPower1 x LED, greenFunction1 x LED, red
Electronic lock: yes
Items supplied: screws: 2 x (M3 x 16 mm) Basic clip spring washers: 2 Nuts: 2
Remarks: cULus - Class 2 source required
Pack quantity: 1 pcs.
Connection: Connector: 1 x M8; coding: A
