Single Phase Induction Motor
Efficiency: 67 Shaft Material: 1045 hot rolled (C-204) steel Voltage Type: AC Motor Frame: 56C Motor Type: Induction Electrically Reversible: Yes Motor Application: General purpose Insulation Class: Class F Horsepower Rating: 3/4 HP IP Rating: IP44 Number of Phases: 1 Service Factor:1.15 Voltage Rating: 110/250 VAC NEMA Design: Design N Synchronous Speed: 1700rpm Junction Box Orientation: F1 Nameplate RPM: 1725rpm Mounting: Rigid base/C-face Overload Type: None Mounting Orientation: Horizontal or vertical
