Image shown is a representation only. Actual product may vary -
-
World Wide Electric Motor 60HP WWEM60-18-364
Electric Motor
Approximate Weight (lbs) 718
Degree of Protection IP23
Enclosure Type ODP
Full Load Amps 70.9
FL Efficiency (%) 95.0
Frame Size 364T
Frequency 60/50 HZ*
Horsepower 60
Insulation Class Class F
Mounting Type Rigid Base
Phase Three-Phase
RPM 1800
Service Factor 1.15
Voltage 230/460
WWEM60-18-364 Specifications
| AC Motor Voltage (VAC) | 230...460 |
| AC Motor Power (HP) | 60 |
| AC Motor Power (KW) | 45 |
| AC Motor Speed (RPM) | 1800 |
| AC Motor Frame (Type) | 364T |
| AC Motor Enclosure (Type) | ODP |
